The San Quentin is for the aggressive hardtail trail rider looking for a blend between singletrack capabilities and extended air time.

Specifications

• Frame

  Series 3 6061 Aluminum, Double Butted Frame, Internal Shifter and Dropper Post Routing, External Brake, 12x148mm Thru-Axle, 73mm Threaded BB

• Front Suspension

  RockShox Recon RL, 110x15mm Boost Spacing, Fast Black Stanchions, 130mm Travel, Bolt-On Thru-Axle, 37mm Offset

• Rims

  Marin Aluminum Double Wall, Disc Specific, 29mm Inner, Pinned Joint, 32H, Tubeless Compatible

• Hub, Rear

  Shimano HF-MT400B, 148x12, Centerlock, Standard Freehub Body

• Hub, Front

  Shimano HF-MT400B, 110x15mm, Centerlock

• Spoke, Nipples

  14g Black Stainless Steel

• Tires

  Vee Tire Co, Flow Snap, 27.5x2.6", MPC Compound, Wire Bead

• Derailleur, Rear

  Shimano Deore, 11-Speed, SGS

• Shift Lever

  Shimano Deore, 11-Speed, SL-5100R

• Crankset

  Marin Forged Alloy, Integrated Steel 32T Narrow Wide Chainring, Boost Spacing

• Bottom Bracket

  External Sealed Cartridge Bearing

• Chain

  KMC X-11 Silver and Black

• Cassette

  SunRace, 11-Speed, 11-51T, ED Black

• Brake, Front

  Shimano BR-MT201 Hydraulic Disc Brake, 180mm Rotor

• Brake, Rear

  Shimano BR-MT201 Hydraulic Disc Brake, 180mm Rotor

• Brake Levers

  Shimano BR-MT201 Hydraulic Disc

• Handlebar

  Marin Mini-Riser, 6061 Double Butted Aluminum, 780mm Width, 28mm Rise, 5º Up, 9º Back

• Stem

  Marin 3D Forged Alloy, 35mm

• Grips

  Marin MTN, Closed EndHeadset

• FSA No 57E, Semi-Sealed Cartridge Bearings, 1 1/8" x 1 1/2”

• Seatpost

  TranzX, YSP18, 1x Remote, Size S 125mm Travel, Size M-XL 150mm Travel, 30.9mm

  • Saddle

    Marin Speed Concept

  • Pedals

    Nylon Platform
