Product Details
Brand: TREK
IN-STORE PICKUP ONLY
Trek Bicycles & Bontrager Spares/Accessories are only available for in-store pickup only

Call or Whatsapp (+91) 7002901755 to talk to our Product Specialists.

Components

• Frame- Size: XS- Alpha Silver Aluminum, curved top tube, internal derailleur and dropper post routing, rack and kickstand mount, 135x5 mm ThruSkew / Size: S , M , ML , L , XL , XXL- Alpha Silver Aluminium, internal derailleur and dropper post routing, rack and kickstand mount, 135x5 mm ThruSkew


• Fork- Size: XS , S- RockShox Judy, coil spring, preload, TurnKey lockout, 42 mm offset for 27.5" wheel, 100 mm QR, 100 mm travel / Size: M , ML , L , XL , XXL- RockShox Judy, coil spring, preload, TurnKey lockout, 46 mm offset for 29" wheel, 100 mm QR, 100 mm travel


• Bottom Bracket- FSA, 73 mm, threaded cartridge, 122.5 mm spindle


• Chain- Shimano LG500


• Crank- FSA Alpha Drive, 30T, 160 mm length


• Shift Levers- Shimano U6000, 10-speed


• Cassette- Shimano CUES LG300, LINKGLIDE, 11-48, 10-speed

• Rear Derailleur- Shimano CUES U6000 GS


• Grips/Bartape- Bontrager XR Trail Comp, nylon lock-on


• Handlebar- Size: XS- Bontrager alloy, 31.8 mm, 5 mm rise, 690 mm width / Size: S- Bontrager alloy, 31.8 mm, 15 mm rise, 720 mm width / Size: M , ML , L , XL , XXL- Bontrager alloy, 31.8 mm, 15 mm rise, 750 mm width


• Stem- Size: XS , S- Bontrager Comp, 31.8 mm, 7-degree, 35 mm length / Size: M , ML , L- Bontrager Comp, 31.8 mm, Blendr compatible, 7-degree, 50 mm length / Size: XL- Bontrager Comp, 31.8 mm, Blendr compatible, 7-degree, 60 mm length


• Saddle- Bontrager Verse Short, stainless steel rails


• Seatpost- Size: XS , S , M- Bontrager alloy, 31.6 mm, 12 mm offset, 330 mm length / Size: ML , L , XL , XXL- Bontrager alloy, 31.6 mm, 12 mm offset, 400 mm length


• Front Brake- Size: XS , S- Tektro HD-M276 hydraulic disc, short reach / Size: M , ML , L , XL , XXL- Tektro HD-M275 hydraulic disc


• Rear Brake- Size: XS , S- Tektro HD-M276 hydraulic disc, short reach / Size: M , ML , L , XL , XXL- Tektro HD-M275 hydraulic disc


• Front Wheel- Bontrager Kovee, double-wall, Tubeless-Ready, 28-hole, 23 mm width, Presta valve,Formula DC-20, alloy, 6-bolt, 100 mm ThruSkew


• Rear Wheel- Bontrager Kovee, double-wall, Tubeless-Ready, 28-hole, 23 mm width, Presta valveFormula DC-22, alloy, 6-bolt, Shimano 8/9/10 freehub, 135x5 mm QR


• Tire- Size: XS , S- Maxxis Ardent Race, tubeless ready, EXO casing, folding bead, 60 tpi, 27.5x2.35" / Size: M , ML , L , XL , XXL- Maxxis Ardent Race, tubeless ready, EXO casing, folding bead, 60 tpi, 29x2.35"


• Pedal- VP-536 nylon platform
